DIY WiFi Smart Motor Automatic Chain Roller Blinds Shade Shutter Drive RF Remote
Product Description
|
roduct Name |
Blinds Chain Motor Controller |
Model |
Mobile APP TUYA WIFI Remote control type;
|
|
Communication Metod
|
Manual button, WIFI / APP tuya control for choice; With some device, can connect with Alexa, google, Homekit, etc. |
Communication Frequency |
RF 433.2MHz, 2.4Ghz |
|
Motor rated voltage / Power
|
DC 12V / 14.4w |
Rated Current |
1.2A |
|
Maximum blinds size |
12ft(3.5m)* 12ft(3.5m) |
Maximum load |
10KG |
|
Adapter voltage |
110V-240V |
Motor torque |
1.35N.M |
|
Shell material |
ABS |
Motor speed |
55RPM |
|
Remote distance |
20m(indoor)-200meter(outdoor) |
Motor noise level |
54dB |
Specification:
Product Name: Blinds Controller
Plug: EU/US/UK/AU (optional) Adapter
Voltage: 110V-240V Control Method: App/Voice/Wifi/Remote
Color: White
Motor Battery: 12V 1200mAh RF Remote Controller
Battery: CR2450
Torque: 1.35N.m
Speed: 55rpm
Frequency: 2.4GHz 433MHz
Voltage: 12V
Rated Current: 1.2A
Max Blinds Size: 3.5*2.5M / 12*8FT
Max Load Weight: 10kg
Distance: No limit, ask for good wifi signal
RF Remote Controller Size: 130*45*11mm/5.1*1.8*0.4in
Drive Motor Size: 160*47*42mm/6.3*1.9*1.7in
Drive Motor Weight: 200g/7.1oz
Packing List:
1 * DIY Smart Blinds Shade Shutter Drive Motor
3 * Gear
1 * Power Adapter
1 * 3M Glue
1 * Bag of Screw
1 * Back Holder
1 * User Manual
About this item:
Smart Blinds Smart Home Automation: Control the new smart blinds by finally adding motorized window shades to your smart home directly with the free smartphone app or its intuitive Touch. Save Time Energy & Money: Compatible with any window shade/blind that has a cord loop or beaded chain (plastic or metal). With a 5-minute DIY installation process at half the price, makes this smart blinds the best choice for window blind/shade automation. One-time Set & Smart for Day & Night: With 15 channels, you can set with different rates to protect your privacy, block out the heat, or let in sunlight. Easier Control Via Alexa/Google/Wifi: Just connect it with Wi-Fi (Tuya), you can control it up or down through voice or APP on your mobile phone. Schedule: Setting open and close time as your like, open when sun rise, and close when sunset
Detailed Images
Product Features:
1.Smart Home Automation:
Automate your existing blinds, shades, curtains in the simplest and most cost-effective way. Motor can set upper & bottom limit positions and limits can be saved even when power off. Simply add motorized shades to your smart home with Smart Blinds Drive Motor!No change of existing blinds , no tubular motor. One touch for intelligent controls.
2.No hub required for pairing with Smart Life App:
This WiFi smart chain blind motor is featured as one touch control via Tuya Smart App for on/off and stop for your connected blinds.Remotely control your house blinds on smart phones no matter where you are,and easily open and close blinds on schedule set in app,as well as countdown option;only 2.4G WiFi compatible.
3.Single or Multi-control:
RF remote is designed as a kit with the WiFi motor to control your blinds in another convenient way after pairing the code,especially fits for the old who just do not know how to operate on smart phones. Just hang up the remote onto the wall with the screws included in the package for saving space in your room.
4.Voice control
Via Amazon Alexa,Google Assistant and Apple Siri for added convenience to open and close blinds when necessary. Wide compatibility supported with vertical blinds, roller blinds,roman blinds, zebra blinds,curtain/drapes and venetian blinds.
5.Powered
By AC adapter with no battery in,so it is a must to plug the adapter into the motor for normal use,saving energy and protecting environment without replacing the battery constantly;Easy mounting and setting with 3-5 minutes DIY at fingertip.
